Specification:

Rated Voltage: 120VAC

Rated Current: 20A max

Frequency: 60Hz

Trip Current: 4-6mA

Tripping speed: 25mS max

Voltage Surge: 6KV (100KHz Ring Wave)

Endurance: 3000 Cycles min

Hit-Pot Test: 1.25KV for 1 min

Approval:  UL943 UL

Cable capacity: #12AWG ,#14AWG，#16AWG，#18AWG

IP Rating :IP50

Autodetect testing

Application: Equipment , Household appliances ,  etc.
