参数Specification:

额定电压Rated Supply Voltage: 120VAC

额定电流Rated Current: 15Amax

工作频率Operating Frequency: 60Hz

跳制电流Trip Current: 4-6mA

跳制时间Trip Time: 25mS max (I_△N>=240mA)

耐浪涌电压Voltage Surge: 6KV (100KHz Ring Wave)

寿命Endurance: 3000 Cycles min (With15ALoad)

耐压Hit-Pot Test: 1.25KV for 1 minute

标准Approval & Standard: UL943(GFCI)

输入插脚类型Input Type: NEMA 1-15 Plug(3P)

输出形式及电源线Output Type and Power Cord: 接线端子可配14AWG-18AWG SJTW的电源线Wire Terminal with 14AWG-18AWG SJTW

防淋雨Rain Proof Design: UL50 3R

应用电器Application: 可用于电阻性负载，电感性负载，马达性负载，如电动工具，剪草机，鼓风机，清洗机，洒水机，以及家用电器Power Tools, Lawnmower, Fan, Sprinkler, House-hold Application, etc.
