参数Specification:

1.额定电压Rated Voltage: 120VAC

2.额定电流Rated Current: 15-20A max

3.工作频率Frequency: 60Hz

4.剩余动作电流Trip Current: 4-6mA

5.脱扣速度Tripping speed: 25mS max

6.浪涌电压Voltage Surge: 6KV (100KHz Ring Wave)

7.寿命Endurance: 3000 Cycles min

8.耐压Hit-Pot Test: 1.25KV for 1 minute

9.认证标准Approval:  UL943  UL

10.接线孔容量Cable capacity: #12AWG ,#14AWG，#16AWG，#18AWG

11.防护等级IP Rating : IP50

12.轻触重置Touch reset

13.断相(L)保护Open-phase protection

14.自检保护Autodetect testing

15.典型应用Application: Equipment , Household appliances ,  etc
